Stainless Steel Threaded Spring Loaded Vertical Check Valve

Working pressure PN16
Working temperature -10°C / +200°C
Connection type DIN2999

Get a quote on WhatsApp

Documents

Product catalog page

PDF 1 page(s) 257 KB EN 01.08.2026

View Download PDF

What it does

Check Valves

A check valve is an automatic safety component that allows fluid to pass in one direction only and closes off reverse flow by itself. It requires no external actuation: closing occurs mechanically when flow stops and back pressure builds up. Check valves are used to prevent backflow and water hammer at pump outlets, to prevent reverse flow on boiler feed lines, and to isolate branches on lines fed from more than one source. Spring-loaded types permit both vertical and horizontal installation, swing types operate with low pressure drop, and dual-plate and disc types are preferred where a short face-to-face dimension is required.

Where it is used

Application areas

01 Chemical - Petrochemical
02 Water - Wastewater
03 Heating - Cooling Systems
04 Maritime Applications
05 Mining Applications
06 Power Stations

Dimensions

Dimension table

5 rows × 5 columns

Stainless Steel Threaded Spring Loaded Vertical Check Valve — Dimension table
DIN2999	kolon_2*	kolon_3*	PN16	kolon_5*
1	GÖVDE	BODY		AISI304 / AISI316
2	DİSK	DISC		AISI304 / AISI316
3	YAY	SPRING		AISI304 / AISI316
4	KAPAK	BONNET		AISI304 / AISI316
5	CONTA	GASKET	PTFE

* This column heading is embedded inside the technical drawing in the source PDF, so it could not be read as text. The values are correct; only the column name still has to be entered manually.
